The sporty short roll winder for foams, films and nonwovens
For inline and offline operation
Powerful 1-shaft machine
Preparation- & wrapping free winding of the new web
Winding with and without core
For industries like: building & roofing Industry, insulation, agriculture & garden, etc.
Technical data – Standard model:
Designed for multi-shift operation
Working width up to 2.000 mm (depending on material)
Winding shaft – Ø: 3” (76,2 mm)
Integrated web edge control for edge rewinding in standard format up to 300 mm roll diameter
Roll change cycle time 30 sec. at 10 m rolls
Mechanical design speed: max. 150 m/min.
Web buffer content: 8 m
Web buffer designed as linear material buffer
YOU HAVE QUESTIONS OR NEED FURTHER INFORMATION?
We are always at your disposal: +49 5458 93661-0
The extremely transparent protection and safety device provides an excellent overview of the whole structure in the machines
Easy access to all machine components
Low maintenance intervals
Ergonomic overall concept
Connector system technology and valve terminal
Integrated remote maintenance
